Non-Slam Nozzle Check
MODEL NO. CNZ
Wafer / 1″(25A) ~ 10″(250A)
수두손실선도
MODEL NO. PCN
Wafer / 12″(300A) ~ 60″(1500A)
수두손실선도
사양
| 구경 | 1″(25A) ~ 60″(1500A) | ||
| 유체 | Oil & Gas, Water, Air, Steam, Sea Water..etc. | ||
| 사용압력 | Class 150~2500 | ||
| 배관연결 | Water, Lug, Double Flange | ||
| 재질 | ①Body | Carbon Steel, Stainless Stell, Duplex, NI_AI_Bronze..etc. | |
| ②Disc | Stainless Steel, Duplex, NI_AL_Bronze..etc. | ||
| ③Guide | Stainless Steel, Duplex, NI_AL_Bronze..etc. | ||
| ④Spring | Stainless Steel, Inconel..etc. | ||
| ⑤Seat | Rubber, PTFE, Stainless Steel, Stellite Overlay. | ||
MODEL NO. SNF
Single Seat Nozzle / 1″(25A) ~ 10″(250A)
수두손실선도
MODEL NO. DNF
Double Seat Nozzle / 12″(300A) ~ 48″(1200A)
수두손실선도
사양
| 구경 | 1″(25A) ~ 48″(1200A) | ||
| 유체 | Oil & Gas, Water, Air, Steam, Sea Water..etc. | ||
| 사용압력 | Class 150~2500 | ||
| 배관연결 | Double Flange, Buttwelding, Hub | ||
| 재질 | ①Body | Cast Iron, Stainless Stell, Duplex, NI_AI_Bronze..etc. | |
| ②Disc | Stainless Steel, Duplex, NI_AL_Bronze..etc. | ||
| ③Guide | Stainless Steel, Duplex, NI_AL_Bronze..etc. | ||
| ④Spring | Stainless Steel, Inconel..etc. | ||
| ⑤Seat | Rubber, PTFE, Stainless Steel Stellite Overlay. | ||
MODEL NO. WNF
12″(300A) ~ 60″(1500A)
사양
| 구경 | 12″(300A) ~ 60″(1500A) | ||
| 유체 | Oil, Water, Air, Steam, Sea Water..etc. | ||
| 사용압력 | Class 150~300 | ||
| 배관연결 | Double Flange | ||
| 재질 | ①Body | Cast Iron, Stainless Stell, Duplex, NI_AI_Bronze..etc. | |
| ②Disc | Stainless Steel, Duplex, NI_AL_Bronze..etc. | ||
| ③Guide | Stainless Steel, Duplex, NI_AL_Bronze..etc. | ||
| ④Spring | Stainless Steel, Inconel..etc. | ||
| ⑤Seat | Rubber, PTFE, Stainless Steel Stellite Overlay..etc. | ||
수두손실선도
